                                Image is for reference, please contact us to get the real picture

                                    | Manufacturer Part Number: | OX4120A-D3-5-10.000-3.3 |
| Manufacturer: | Raltron |
| Part of Description: | XTAL OSC OCXO 10MHZ 3.3V TH |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Stock Condition: | 48 In Stock |
| Ship From: | Hong Kong |
| Shipment Way: | DHL/Fedex/TNT/UPS/EMS |
| Type | Description |
|---|---|
| Series | 2000 |
| Package | Bulk |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | OCXO |
| Frequency | 10 MHz |
| Function | - |
| Output | LVCMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±50ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | - |
| Ratings | - |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP, 4 Leads (Full Size, Metal Can) |
| Size / Dimension | 0.819" L x 0.520" W (20.80mm x 13.20mm) |
| Height - Seated (Max) | - |
