Image is for reference, please contact us to get the real picture
| Manufacturer Part Number: | MAL250055153E3 |
| Manufacturer: | Vishay BC Components/Beyshlag/Draloric |
| Part of Description: | CAP ALUM 15000UF 350V 5000H |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Stock Condition: | 77 In Stock |
| Ship From: | Hong Kong |
| Shipment Way: | DHL/Fedex/TNT/UPS/EMS |
| Type | Description |
|---|---|
| Series | 500 PGP-ST |
| Package | Box |
| Part Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 350 V |
| ESR (Equivalent Series Resistance) | 9mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 23 A @ 100 Hz |
| Ripple Current @ High Frequency | 34.5 A @ 10 kHz |
| Impedance | 8 mOhms |
| Lead Spacing | 1.252" (31.80mm) |
| Size / Dimension | 3.008" Dia (76.40mm) |
| Height - Seated (Max) | 8.693" (220.80mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
Stock Status: 77
Minimum: 1
Price: $151.62000
